Emergency Guide

Key Fob Dead? How to Unlock & Emergency Start Your Jaguar Land Rover

Your key fob battery has died and you're locked out. Don't panic — every Jaguar and Land Rover has an emergency key blade hidden inside the fob and a backup start location. Here's how to get into your car and start the engine when your smart key stops working.

It's one of the most common calls we get: "My key fob isn't working and I can't get into my car." Whether you're in a supermarket car park, at the airport after a long trip, or stranded on your driveway, a dead key fob battery can leave you feeling helpless.

The good news is that every modern Jaguar and Land Rover has a backup system built in. You just need to know where to find the emergency key blade, where the hidden door lock is located, and how to start the engine using the emergency start feature.

This guide covers the complete process for all JLR models.

Step 1: Remove Key Blade Step 2: Unlock Door Step 4: Start Engine
Share this guide:
1

Step 1: Unlocking the Door with the Emergency Key Blade

When the key fob's battery is dead, the first step is to gain entry to your vehicle manually.

Remove the Emergency Key

Look for a small release button or tab on the back or side of your smart key fob. Press or slide it to release and slide out the metal emergency key blade.

Locate the Door Handle Cover

On the front driver's side door handle, you will find a small cover at the end (usually the end facing the rear of the car). There is a small hole on the underside of this cover.

Visual Guide: Look for a close-up of the door handle with the small hole on the underside where you'll insert the key.

Remove the Cover

Insert the tip of the emergency key (or the key itself) into the hole on the underside of the door handle cover. Gently pry or lever the cover off to reveal the traditional key lock cylinder behind it.

Diagram: The emergency key is inserted into the hole, with the cover being pried off to expose the lock cylinder.

Unlock the Door

Insert the emergency key blade into the exposed lock cylinder. Turn the key clockwise to unlock the driver's door.

Illustration: The key being turned clockwise in the lock cylinder behind the removed cover.

Important Note

When you open the door, the vehicle's alarm may sound. This is normal and will stop once you start the engine.

2

Step 2: Find the Hidden Door Lock

Modern JLR vehicles don't have a visible keyhole on the door handle — but there is one hidden underneath a cover. The location varies slightly by model.

Land Rover Models

Range Rover, Defender, Discovery, Evoque, Velar, Discovery Sport

The emergency lock cylinder is hidden behind a small cover on the driver's door handle.

How to Access It:

  1. 1

    Insert the emergency key blade into the small slot or gap at the front edge of the door handle cover

  2. 2

    Use the blade as a lever to gently pry off the plastic cover. This will expose the mechanical lock cylinder underneath

  3. 3

    Insert the key blade into the lock and turn counter-clockwise (anti-clockwise) to unlock the door

Jaguar Models

F-Pace, E-Pace, I-Pace, XF, XE, F-Type

On most Jaguar models, the lock cylinder is hidden behind a cover on the driver's door handle or on the front passenger door handle depending on the model.

How to Access It:

  1. 1

    Look for a small removable cover on the back portion of the door handle (the part closest to the car body)

  2. 2

    Use the key blade to carefully pry this cover off, revealing the lock cylinder

  3. 3

    Insert the blade and turn to unlock the door

3

Step 3: Prepare for the Alarm

Important Warning

When you unlock the door using the emergency key blade, the alarm will almost certainly go off. This is normal — the car doesn't recognise that you've unlocked it with a legitimate key because the fob battery is dead and can't send a signal.

Don't panic. The alarm will stop once you complete the emergency start procedure in the next step.

4

Step 4: Start the Engine Using Emergency Start

Once inside the vehicle, you'll see a message saying "Smart Key Not Found" or "Key Not Detected — Position As Shown". This is where the emergency start backup feature comes in.

Emergency start methods diagram showing key fob positions for Jaguar Land Rover vehicles

Every JLR vehicle has a designated spot where you can hold the key fob so the car can read the passive transponder chip inside it — this chip doesn't require battery power.

Land Rover Emergency Start Location

On Land Rover models, the emergency start position is on the side of the steering column.

Look for small markings or a key symbol on the left-hand side of the steering column cover, near your left knee. Hold the key fob flat against this marked position with the buttons facing outward.

To start the engine:

  1. 1

    Hold the key fob flat against the steering column in the marked position

  2. 2

    Keep the fob in place

  3. 3

    Press the brake pedal firmly

  4. 4

    Press the Start/Stop button

The car should recognise the transponder chip in the fob and allow the engine to start. The alarm will stop once the engine is running.

Jaguar Emergency Start Location

On Jaguar models, the emergency start position varies by model but is typically in one of these locations:

F-Pace, E-Pace, I-Pace

Hold the fob flat against the lower left side of the steering column where marked with a key symbol

XF (X250/X260)

Some models have a dedicated slot near the driver's left knee. On others, hold the fob against the steering column

XE

Hold the fob against the steering column on the left side

XJ

Hold the fob flat against the fascia below the auxiliary switch pack (below the fog light switch)

To start the engine:

  1. 1

    Position the fob flat against the marked location (buttons facing outward)

  2. 2

    Keep the fob firmly in place

  3. 3

    Press the brake pedal

  4. 4

    Press the Start/Stop button

Tip: If it doesn't work on the first attempt, try moving the fob slightly around the marked area while pressing the start button.

What If the Emergency Start Doesn't Work?

If you've followed the steps above and the car still won't start, try these troubleshooting tips.

Move the fob around the area

The exact position matters. Slide the fob slowly across the steering column area while pressing the start button. Some owners find the sweet spot is slightly higher or lower than the marked position.

Press harder

Make sure the fob is flat against the surface with good contact. The transponder chip needs to be close to the reader.

Try your second key fob

If you have access to your spare key (perhaps a family member can bring it), try that fob instead. The first fob's transponder chip may be damaged, not just the battery.

Check if the fob battery is completely dead

If the battery has a tiny amount of charge left, the fob may be interfering with the emergency start. Remove the battery from the fob entirely, then try the emergency start again.

Check the vehicle battery

If the car's main 12V battery is also flat (which can happen if the car has been sitting unused), no amount of fob positioning will help. You'll need to jump-start or charge the vehicle battery first. See our guide on Discovery Sport key fob issues after a flat battery.

Once You're Moving: Replace That Battery

The emergency start feature is exactly that — for emergencies only. Once you've got the car running, your priority should be replacing the key fob battery.

Battery Type: CR2032

JLR key fobs use a CR2032 lithium coin cell battery. You can pick one up from any supermarket, petrol station, or hardware shop for a few pounds.

To replace the battery:

  1. 1

    Remove the emergency key blade from the fob

  2. 2

    Use the blade to pry apart the two halves of the fob case

  3. 3

    Note the battery orientation (positive side usually faces up)

  4. 4

    Remove the old battery and insert the new CR2032

  5. 5

    Snap the fob back together and reinsert the key blade

  6. 6

    Test by pressing the lock/unlock buttons

See our complete guide to JLR key fob battery replacement for detailed step-by-step instructions.

View Battery Replacement Guide

Tips to Avoid Getting Stranded

A dead key fob battery is preventable. Here's how to avoid the situation in the future.

Don't ignore the warning

When your dashboard displays "Smart Key Battery Low", replace the battery within a few days. The warning typically gives you a few weeks of notice, but don't push your luck.

Replace both fobs at the same time

If one battery is dead, the other is likely not far behind. Replace both to avoid a repeat situation.

Carry a spare CR2032

They're tiny and cheap. Keep one in your wallet, glovebox, or bag.

Know where your emergency blade is

Before you need it, practise removing the blade from your fob so you're not fumbling in a stressful situation.

Know where the door lock is

Find and identify the hidden lock cover on your door handle now, while you're not panicking in a car park.

Keep your spare key accessible

Don't store both keys together. Keep one at home or with a trusted person.

When to Call a Professional

The emergency key and start backup should get you going in most situations. However, you should call a professional if:

The emergency start doesn't work despite trying all positions

The vehicle battery is also flat and you can't jump-start it

The emergency key blade won't turn in the lock (the lock cylinder may be seized)

You've lost all your keys and don't have access to an emergency blade

The fob still doesn't work after replacing the battery

Quick Reference Summary

Locked out with a dead key fob? Here's the quick version:

  1. 1

    Remove the emergency key blade from inside your fob (press the release button)

  2. 2

    Find the hidden lock on the driver's door handle (pry off the small cover with the blade)

  3. 3

    Insert blade and turn counter-clockwise to unlock

  4. 4

    The alarm will sound — ignore it for now

  5. 5

    Get inside and hold the fob flat against the steering column (look for markings)

  6. 6

    While holding the fob in position, press the brake and press Start

  7. 7

    The engine will start and the alarm will stop

  8. 8

    Replace your key fob battery as soon as possible (CR2032)

Battery Type

CR2032 lithium coin cell

Emergency Start

Left side of steering column
